 Dimension: |
Notes: |
 |
- This Toilet is Designed to Round-In at adjustable
Dimension of 10"~12" From Finished
wall to C/L of outlet.
- Dimension Shown for location of Supply is
Suggested.
|
|
| FEATURES & BENEFITS |
- Rated#1 2-piece toilet by NAHBRC
- The only water closet on earth with
no flexible seal holding the water back.
- No flexible seals, no maintenance.
- Tamperproof flush cannot exceed 1.6
GPF/6.0LPF meaning sustainable water savings.
- Made for retrofitting older toilets.
- Fully adjustable...can fit both 10"
and 12" rough-ins.
- Huge 10"x20" footprint
avoids costly flooring repairs.
- Best flushing toilet ever: No double
flushing
- Large water surface for bowl cleaning
action,
- Ultra-low flush vitreous china water
closet with Round, Elongated or Elongated ADA bowl.
- Global tech fill valve.
- Meets local building codes and rebate
requirements.
- Meets or exceeds all ANSI/ASME/CSA
low-consumption water conservation requirements.
- Certified and listed by IAPMO
- Approved by the city of Los Angeles.
- Lifetime guarantee on porcelain.
|
|
| Superior Flush Performance |
INSPECTION
ITEMS |
Test
Result |
Rim Wash |
Pass |
Solid ball Test |
100 |
100 |
100 |
Blue America Standard ball |
3 |
3 |
3 |
Trap way Diameter |
48mm/50.8mm |
Messo Paster (650g) |
650g |
Water consumption |
6.0L |
3 Flush Without Media |
Pass |
Cheesecloth |
Pass |
Trap Seal Restoration |
65mm |
Restoration Area |
192x160mm |
|
| Compliance
Certifications-Meets or exceeds the following specification: |
- Meets
ASME A112.19.2M for Vitreous China Fixtures-includes
flush performance, ball pass diameter, trap seal depth
and all dimensions.
|
